Detailed Information
| Material | Toray T700 carbon with silky coating |
| Wheelbase | 220mm |
| Middle Mouting Hole | 30.5x30.5mm |
| Rear Mouting Hole | 20x20/25.5*25.5/30.5x30.5mm |
| Camera Size | 19x19/20x20mm |
| Supported System | O3/Analog/Vista/Walksnail/HDZero |
| Weight | Weight 129g(Excluded TPU) |
| Packing List | |
| 5mm Arm 16~19mm mounting - 4 | |
| 2mm Top Plate - 1 | |
| 2.5mm Middle Plate - 1 | |
| 2.5mm Bottom Plate - 1 | |
| CNC Side Plate - 2 | |
| Aluminum Column M3*Φ5.5*23 - 4 | |
| SMA Antenna Mount - 1 | |
| Bottom Plate Front Protective Mount - 1 | |
| M5 Gopro Mount - 1 | |
| Arm Guard - 4 | |
| 915 Rx Antenna Mount - 1 | |
| Isolation Column - 2 | |
| Capacity Supporter - 1 | |
| DJI O3 VTx Mount - 1 | |
| UFL Antenna Mount - 1 | |
| Cam Spacer - 2 | |
| M5 Nut - 1 | |
| M5*20 Screw - 1 | |
| Battery Anti-slip Mat -1 | |
| 250*20mm Strap - 1 | |
| 220*20mm Strap - 1 |
